| 起源の場所: | ドイツ |
| ブランド名: | HIMA |
| 証明: | CO.CQ |
| モデル番号: | HIマトリックス F35 010 30 |
HIMatrix F35 010 30 HIMA compact safety-related controller |
Product Detail
The HIMatrix F35 is a compact safety‑related controller from HIMA Paul Hildebrandt GmbH + Co KG (HIMA).It is designed for safety‑critical applications (machines, plants, process
industries) up to high safety integrity levels.The version “010 30” is one model (or sub‑variant) of the F35 family
(you may find part‑numbers like F35 01, F35 011, etc).
FAQ of HIMatrix F35 010 30
Q1. What safety integrity levels does this product support?
A1. The HIMatrix F35 family is certified for use up to SIL 3 (per IEC 61508/61511/62061) and Category 4 / PL e (per EN ISO 13849‑1) in its standard form. Depending on variant or system configuration,
higher certification (e.g., SIL 4 in rail/other niche) might be possible in the HIMatrix series but you must check specific certificate.
Q2. What programming tool is required?
A2. The HIMatrix F35 has variants for two programming tools: SILworX (HIMA’s engineering environment) and ELOP II Factory. Your choice depends on the specific
variant of the controller (e.g., F35 01 SILworX vs F35 01 ELOP II).
Q3. Can I use this controller in a hazardous area (Ex zone)?
A3. Yes — according to documentation it is suitable for mounting in Ex‑Zone 2 (when installed as per the manual) for certain variants. However, you must ensure
compliance with relevant explosion protection certifications and
installation rules for your site.
Q4. What are the inputs/outputs available?
A4. Standard configuration: 24 digital inputs, 8 digital outputs, 2 counters, 8 analog inputs. . Analog inputs allow the input signals to
be captured as INT values (0 … ~3000 corresponding to 0…30 V) and
thresholds are used to generate BOOL for logic.
